Aluminum CNC Cut Machine 3200x14000mm Gantry Fiber Laser Cutting Equipment 380V

Brand Name : YUAN

Model Number : 3200x14000

Certification : CE,ISO,UV

Place of Origin : China

MOQ : 1 set

Price : 5000-25000USD

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 50 sets

Delivery Time : 25 days

Packaging Details : wooden box

Product name : plasma metal cutting machine

Application : Industrial Metal Cutting

Cutting mode : Plasma Cutting+ Flame Cutting

Cutting material : Metal Stainless Steel Carbon Steel Aluminum

Voltage : 220V/380V

Color : Customizable

Contact Now

hot sale metal cutter gantry plasma cutting machine cnc for aluminum shape cut

Product Description:

1. This cutting machine is widely used in cutting sheet metal to various size and shape.

2. This cutting machine adopts gantry type structure,double driving and linear guide,plasma cutting torch number is set according to customer' request. Cutting plate is normally 1-60mm thick.

3. Gantry structure double driving increase the work stability and accuracy; double lifting devices makes operation simple and smoother.

Our plasma cutting machine features:
1. We set the automatic high arc pressure adjusting device: when the plate shape changes a little during processing, the spearhead will adjust itself to avoid damage of the plate.
2. We set collision-prevention device to protect the spearhead from damage when it is suddenly power off.
3. We do fine grinding processing to all the contact surface to make sure they joint closely.
4. A set of SigmaNest (for free)will send together with the machine to save the material for you.
Main configuration:
Item Unit Parameters
Equipment structure / Gantry Structure
Gauge mm 3000-14000(According to user's requirement)
Gauge Length mm extended accroding to requiremet(2 m/setion)
Cutting width mm Gauge minus 800(two cut torch)
Cutting Length mm Rail length minus 2000
Flame cutting thickness mm 5-200mm
Plasma cutting thickness mm 1-60(depends on plasma power supply)
Flame Cutting Torch Group Number Set 1
Plamsa Cutting Torch Group Number Set 1
Cutting Model / Flame(oxygen/acetylene/propane)Plasma H35/F5/和0(air/oxygen/nitrogen/hydrogen)
Drive motor / Domestic precision stepper(Optional :Panasonic servo/domestic servo)
Reducer / Planetary Reducer(Optional German Newcate/Shanghai Bitpass)
Guide rail Kg 24(optional 36/48)
CNC System / Shanghai Jiangtong university Fang F2100
Plama Power / Huayuan ,Hypertherm,Thermadyne
Nesting software / Starcam (Optional :Fastcam)
Ignition device / Automatic
Torch lifing range mm 200
Torch height controller / flame electric controller/plasma arc voltage controller(optional:flame capcitor controller)

Detailed Images

Aluminum CNC Cut Machine 3200x14000mm Gantry Fiber Laser Cutting Equipment 380V Aluminum CNC Cut Machine 3200x14000mm Gantry Fiber Laser Cutting Equipment 380V
Aluminum CNC Cut Machine 3200x14000mm Gantry Fiber Laser Cutting Equipment 380V Aluminum CNC Cut Machine 3200x14000mm Gantry Fiber Laser Cutting Equipment 380V
Aluminum CNC Cut Machine 3200x14000mm Gantry Fiber Laser Cutting Equipment 380V Aluminum CNC Cut Machine 3200x14000mm Gantry Fiber Laser Cutting Equipment 380V
Aluminum CNC Cut Machine 3200x14000mm Gantry Fiber Laser Cutting Equipment 380V Aluminum CNC Cut Machine 3200x14000mm Gantry Fiber Laser Cutting Equipment 380V
Famous brand CNC control system, Starfire & Hypertherm are optional Head protection device, to avoid the cutting machine spearhead from damage

Aluminum CNC Cut Machine 3200x14000mm Gantry Fiber Laser Cutting Equipment 380V
